Separatory Funnel Shaker

< >

Speed Range ：50~300rpm，Vertical Stroke Length ：40mm

Model: WS-1 PLUS

Order NO.: 32012KB

6794

Specific parameters will be adjusted according to product upgrades, without notice.

Quotation Request

PRODUCT OVERVIEW

Description

Intensive vertical reciprocal quick solvent extraction shaking unit.
The separatory funnel shaker is able to shake six samples under identical conditions for any series or comparative protocols in chemistry, biotech, and medical labs.

Features
> Intensive vertical shaking
> Shaking of 6 samples under identical conditions possible
> Mostly used in chemical, biotech, and medical laboratories
> The speed can be set between 50 and 300 rpm
> The timer can either be set on continuous or between 0 and 60 min
> Flasks of up to 40 mm width can be used
> Bright TFT display for convenient speed monitoring
> Wide speed range and high precision of the speed control
> Feedback loop to a digital controller
> At the end of a shaking session the device stops automatically with an audible alarm
> Easily adjustable flask holder (max. 5 flasks per side)
> It comes with six funnel holders as standard capable off accommodating up to 1000ml
> WS-1 PLUS entails a flask holder to adjust the shaking angle

Accessories
Included 500mL Separatory Funnel Holder (Order No.: 32500)
1L Separatory Funnel Holder (Order No.: 32501)
2L Separatory Funnel Holder (Order No.: 32502)

Specifications

Model	WS-1 PLUS
Motion Type	Vertical reciprocal
Speed Range (rpm)	50 ~ 300
Accuracy(± rpm)	± 1
Vertical Stroke Length (mm)	40
Timer	60 min or continuous operation
Overall (W×D×H) (mm)	445×730×505
Max. Load per each Side (kg)	3
Power (W)	90
Fixture	6
Weight (Kg)	90
Shaking Angle	Angle adjustable 0-16o
Order No.	32012KB
